Specifications
Physical Characteristics
Dimensions
| 6.92 in. L x 3.09 in. H x 0.56 in. D 175.8 mm L x 78.6 mm W x 14.2 mm D |
| Weight | 9.38 oz/266 g |
| Display | 6.5 inch/16.51 cm HD+, 720 x 1600, 450 NITS |
| Touch Panel | Capacitive multi-touch |
| Power | Removable, rechargeable Li-Ion battery, 5,000 mAh; 19.35Wh |
| SIM | Dual nano SIM or One NANO one Micro SD |
| Network Connections | WLAN, WWAN, WPAN, Type C USB 2.0 |
| Notifications | Audible tone; multi-color LEDs; vibration |
| Keypad | On-screen touch keypad |
| Voice and Audio | Speaker 1 Watt Two (2) microphones Audio headset supported from USB-C port or Bluetooth |
| Buttons | Scan button on each side; volume up/down button; power button; Programmable button |
Performance Characteristics
| CPU | Qualcomm Snapdragon™ SM6375 Octa- (8) Core 2.2 GHz (2) & 1.8 GHz (6) |
| Operating System | Android; for supported Android versions, visit: www.zebra.com/android-versions |
| Memory | 4 GB RAM/64 GB Flash |
| Security | Verified boot, secure boot |
User Environment
| Operating Temp. | 14°F to 122°F/-10°C to 50°C |
| Storage Temp. | -40°F to 158°F/-40°C to 70°C |
| Humidity | 5% to 95% non-condensing |
| Drop Specifications | 4 ft./1.2 m drop to concrete per MIL-STD 810G across operating temperature 5 ft./ 1.5 m drop to concrete per MIL-STD 810G across operating temperature with rugged boot |
| Tumble Specification | 1,000 tumbles, 1.6 ft./0.5 m |
| Sealing | IP65 and IP67 |
| Vibration | Sine: 4 g’s peak, 5 Hz to 2 kHz, 1 hour duration per axis Random: 0.04 g²/Hz or 6 g RMS, 20 Hz to 2 kHz |
Electrostatic Discharge (ESD) | +/-15 kV air discharge, +/- 8 kV direct discharge; +/- 8 kV indirect discharge |
Interactive Sensor Technology (IST)
| Light Sensor | Automatically adjusts display brightness, display backlight |
| Motion Sensor | 3-axis gyroscope; 3-axis accelerometer |
| Proximity Sensor | Automatically detects when the user places the handset against head during a phone call to disable display output and touch input |
Data Capture
| Scanning | SE4100 1D/2D Scan Engine, SE4710 1D/2D Scan Engine3 |
| Camera | Rear camera: 13 MP auto-focus camera with user controllable LED flash Front camera: 5 MP |
| NFC | Reader/Writer: ISO 14443 Type A and B, MIFARE, FeliCa™, ISO 15693, NFC Forum Tag Types 1 to 5; Host Card Emulation, NFC Forum compliant |
Wireless WAN Data
| Radio Frequency Band | Support for 3GPP Rel-15,SA&NSA,4x4 MIMO,NRCA,DLCA 5G FR1: n1/2/3/5/7/8/20/28/38/40/41/66/77/78 LTE: B1/2/3/4/5/7/8/20/28/B38/39/40/41/42/43 UMTS: B1/2/4/5/8 GSM: 850/900/1800/1900 |
| GPS | GPS with A-GPS; Glonass; BeiDou; Galileo |
Wireless LAN
| Radio | Wi-Fi 5 802.11a/b/g/n/ac/d/h/i/r/w/k IPv4, IPv6 |
| Data Rates | 2.4 GHz: 802.11b/g/n — 20 MHz, 40 MHz — up to 150 Mbps 5 GHz: 802.11a/g/n/ac – 20 MHz, 40 MHz, 80 MHz – up to 433 Mbps |
| Operating Channels | Bands Of Operation: 2.4 GHz: 2.4 GHz to 2.497 GHz channels 1-13 Band of operation 5 GHz: 20 MHz channels: 5.15 GHz — 5.25 GHz (channels 36-48) 5.25 GHz — 5.35 GHz (channels 52-64) 5.470 GHz — 5.725 GHz (channels 100-140,144) 5.725 GHz — 5.825 GHz (channels 149-161) 5.825 GHz — 5.850 GHz (channel 165) 40 MHz channels (38, 46, 54, 62, 102, 110, 118, 126, 134, 142, 151, 159) 80 MHz channels (42, 58, 106, 122, 138, 155) Actual operating channels/frequencies and bandwidths depend on regulatory rules and certification agency |
Security and Encryption | WEP Encryption WPA-Personal and WPA-Enterprise security modes with TKIP encryption WPA2-Personal and WPA2-Enterprise security modes with TKIP and AES encryptions. WPA3-Personal and WPA3-Enterprise security; EAP-TTLS (PAP, MSCHAP, MSCHAPv2); PEAPv0-MSCHAPv2; PEAPv1-EAP-GTC; EAP-TLS |
| Fast Roam | 802.11r (Over-The-Air) |
| Certifications | WFA 802.11ac; WFA 802.11n; WFA WMM; WFA WPA and WPA2 certification in Personal & Enterprise modes; WFA WPA3; WFA Wi-Fi Direct |
Wireless PAN
Bluetooth
| Bluetooth 5.1 BLE, Class 2 |
Warranty
Subject to the terms of Zebra’s hardware warranty statement, the TC15 is warranted against defects in workmanship and materials for a period of one (1) year from the date of shipment. For complete warranty statement, please visit |
Environmental Compliance
RoHS Directive 2011/65/EU; Amendment 2015/863; REACH SVHC 1907/2006 For a complete list of product and materials compliance, please visit |
Recommended Services
Protect your TC15 mobile devices with Zebra OneCare™ SV, the right-priced service for Zebra’s right-priced mobile devices. You get two years of protection against failure, coverage for normal wear and tear, live and online technical support, priority repair turnaround time and free shipping, as well as cloud-based visibility into reports on your devices — including repairs, tech support cases, contracts, LifeGuard Analytics for Android security patch status, and more. For more information on recommended services, please visit
|
Regulatory
| For Regulatory information, please visit www.zebra.com/tc15 |
Footnotes
1. Enterprise Mobility Total Cost of Ownership: from the Expected to the Unexpected — Uncovering the True Costs of Mobile Solutions for Frontline Mobile Workers, VDC Research Group, October 2020 2. Future upgrades and updates will not support additional Wi-Fi 6 functionality 3. Scan engine availability varies by country 4. Requires sideloading |
Mobility DNA™ Professional Integrated Solutions
Mobility DNA solutions help you get more value out of our mobile computers by adding functionality as well as simplifying deployment and management of our mobile devices. For more information on these Zebra-only features, please visit Mobility DNA is available on Android only. Features may vary by model and a Support Contract may be required. To learn which solutions are supported, please visit: |
